WattStopper EOPC-100-W – WIRELESS RF PIR OCCUPANCY SENSOR

WattStopper EOPC-100-W – WIRELESS RF PIR OCCUPANCY SENSOR

WIRELESS RF OCCUPANCY SENSORS ARE IDEAL FOR RETROFIT APPLICATIONS WHERE IT IS DIFFICULT TO INSTALL WIRING TO A CEILING MOUNT SENSOR. THE EXTENDED RANGE EOPC-100 SENSORS ARE PERFECT FOR APPLICATIONS INCLUDING SMALL CONFERENCE ROOMS, PRIVATE OFFICES, EXECUTIVES OFFICE, HALLWAYS AND STORAGE ROOMS. THEY DETECT MINOR MOTION UP TO 15’ AWAY AND MAJOR MOTION UP TO 22’ AWAY WHEN MOUNTED AT 8’. COVERAGE DEPENDS ON A CLEAR LINE OF SIGHT TO THE MOTION – BY WATTSTOPPER

  • Description
  • SPECS
  • MANUAL
  • Please visit literite.com for our new store!
  • NON VERIFIED

Description

This is the wireless RF PIR occupancy sensor. The EOPC-100 Wireless RF PIR Occupancy Sensor works with EOSW-100 Series RF Wall Switches to turn lights on and off based on occupancy. The sensor mounts on the ceiling and provides 360° passive infrared coverage. EOPC-100 wireless sensors operate on power supplied by two photovoltaic panels capable of reaching a full charge in 6 hours when the ambient light level is 20 footcandles (215 lux). Each sensor can be paired with multiple loads controlled by RF wall switches. Paired loads configured for automatic-on operation turn on when a sensor transmits an RF signal that it has detected occupancy. As long as the sensor detects occupany it continues transmitting signals to the paired wall switch receivers. All paired loads turn off when no occupancy has been detected for the duration of the selected time delay. Check out Wattstopper DLM products here.

  • Wireless RF occupancy sensors work with EOSW-100 Series RF wall switches
  • Detection Signature Processing to eliminate false triggers and provide immunity to RFI and EMI
  • Trimpot for sensitivity adjustment
  • Test mode allows quick and easy set up
  • Includes plate for mounting to single- or double-gang junction boxes or ceiling tile
  • Reversible magnetic/adhesive disc for surface mounting
  • Sensor coverage tested to NEMA Guide Publication WD 7-2000

 WS-Installation-EOPC-100 SERIES

  • Powered by 2 photovoltaic panels; operates for up to 72 hours in total darkness
  • Photovoltaic panel operating range: 3-100 footcandles (32-1076 lux)
  • Optional battery (CR2032, or equivalent)
  • Multilevel Fresnel lens provides 360° coverage
  • Adjustable PIR sensitivity
  • Pairs with RF Wall Switch(es)
  • Frequency: 902 MHz, helical antenna
  • Mounting options: ceiling tile, junction box, surface mount (adhesive or magnetic)
  • Operating conditions: for indoor use only; 32-131°F (0-55°C); 5-95% RH, non-condensing
  • UL and cUL listed
  • FCC part 15 compliant
  • Five-year warranty
