Bodine GTD20A Generator Device

Description

Bodine GTD20A Generator Device. Branch Circuit Emergency Lighting Transfer Switch (BCELTS) Switch Bypass Device (Automatic Load Control Relay, ALCR) First Dual Listed Emergency Lighting Control Device for UL 1008 and UL 924 Universal Input.

Benefits

Allows generator supplied emergency lighting regardless of wall
switch position
• Energy costs savings benefits by eliminating constant night lighting
• Can be used with most incandescent, fluorescent and LED lighting
• Can be used as either a branch circuit emergency lighting transfer switch
(BCELTS) or switch bypass (ALCR)

Specifications

UL Listed for US and Canada under UL 924
UL Listed for the US under UL 1008

Full Warranty
5 Years (NOT pro-rata)

Universal Input Voltage
120 Through 277 VAC, 50/60 Hz

AC Input Current
45 mA
(Sensing Circuit Only)

AC Input Power Rating
4.0 Watts
(Sensing Circuit Only)

Approved Lighting Loads
Any Type

Lighting Load Rating
20 A Maximum

Temperature Rating (Ambient)
-20°C to +55°C (-4°F to +131°F)

Dimensions
9” x 6” x 3.5” (229 mm x 152 mm x 89 mm)
Mounting 8.5” x 2.5” (216 mm x 63.5 mm)
Weight
5 lbs. (2.3 kg
